Data Center Cable Gland

Get Instant Quote

YDT -
Manufacturer

Ensuring Uninterrupted Data Flow

Core value positioning: Our company provides precise connection, sealing, protection, and electromagnetic shielding solutions for the efficient, stable, and secure transmission of "data bloodline" (power and signal cables) throughout the entire lifecycle of the data application industry, supporting the reliable operation of computing power from supercomputing centers to edge nodes.

Core pain points in the data application industry and your company's solutions

1. Optimization of high-density wiring space

-Pain point: The internal space of data center cabinets, server clusters, and switches is extremely tight, requiring miniaturization and modular solutions.

Our solution:

Miniature connector: Provides small metal (brass/stainless steel) or nylon connectors such as M8/M12/M16, suitable for high-density ports (such as QSFP optical modules, server power interfaces).

Thin design: Low profile joints reduce space occupation and optimize airflow channels.

Flexible management of corrugated pipes: Small diameter corrugated pipes (⌀ 4mm - ⌀ 12mm) are grouped to protect jumper wires and reduce clutter.

Application scenarios: Cable management at the back of servers, TOR switch port panels, fiber optic patch panel (ODF) jumper protection.

2. Electromagnetic compatibility (EMC) and zero signal interference

Pain points: GPU clusters and high-frequency switches generate electromagnetic interference, leading to signal attenuation and increased bit error rates.

Our solution:

Metal joint/armored joint: Provides 360 ° electromagnetic isolation with>90dB shielding effectiveness, and is key for shielding server power input ports (preventing interference leakage). Protect high-speed signal lines (25G/100G Ethernet InfiniBand）。

Grounding integration design: seamless connection between metal joints and cabinet grounding system to enhance overall EMC performance.

Application scenarios: GPU server cabinet, high-speed switch inlet and outlet, edge computing gateway.

3. Efficient heat dissipation and thermal management

Pain point: High power equipment (single cabinet>20kW) needs to maximize heat dissipation efficiency, and connectors must not obstruct the air duct.

Our solution:

Optimization design for porosity: Metal joints use hollow locking nuts, while nylon joints reduce physical volume and lower airflow resistance.

High temperature resistant materials: Nylon joints (temperature resistance>120 ℃), stainless steel corrugated pipes (temperature resistance>300 ℃) suitable for high temperature areas.

Thermal conduction assistance: Metal joints help with local heat conduction and prevent hot spot accumulation.

Application scenarios: High density server cabinet inlet, liquid cooled cabinet cable penetration point.

4. Fire safety and compliance certification

Pain point: The risk of fire spreading in the computer room is high, and it needs to meet the world's top fire prevention standards.

Our solution:

Flame retardant material: Nylon joints/corrugated pipes have been certified by UL94 V-0, NFPA 262 (Plenum grade), and EN 45545-2 (rail transit).

Low Smoke Zero Halogen (LSZH): Compliant with ISO 6722 standard, non-toxic smoke release in fire.

Fireproof sealing integration: The joint cooperates with fireproof mud/expansion sealant to ensure the integrity of cable penetration holes for fire protection.

Application scenarios: Space under elevated floors/ceilings in data centers, and micro module machine rooms.

5. Physical protection and cable safety

Pain point: Cable interruption caused by trampling, squeezing, or rodent bites (especially at edge nodes)

Our solution:

Explosion proof armored joint: provides IK10 impact protection for outdoor edge equipment, resisting external damage.

Wear resistant corrugated pipe: PA/PUR corrugated pipe covers exposed cable sections to prevent wear (such as underfloor wiring).

Tensile armor locking: The armor joint fixes the cable armor layer and can withstand a tensile force of>1000N.

Application scenario: edge computing box inlet, outdoor cabinet, data center cold channel underfloor cable.

6. Adaptability to harsh environments

Pain point: Edge devices deployed in high temperature, humid, salt spray environments (such as factories, coastal areas)

Our solution:

IP6X/IPX9 sealing: 316 stainless steel joints resist salt spray, nylon joints resist UV aging

Corrosion resistant corrugated pipe: PP/PVDF corrugated pipe resistant to chemical corrosion (suitable for industrial edge nodes)

Application scenarios: Smart factory edge servers, coastal 5G base station supporting data center boxes

Learn More

Uncompromising Cable Protection For Data

The core value proposition of our company's solution

1. Ensure zero data interruption: reduce signal failure rate by>40% through>90dB EMI shielding and IP68 protection

2. Improve energy efficiency ratio: Optimize heat dissipation design to reduce wind resistance and help data center PUE drop below 1.2

3. Passed global top-level certification: meets UL 94V-0, NFPA 262, TIA-942, EN 50600 and other standards

4. Reduce TCO (Total Cost of Ownership): Extend cable lifespan by more than 50% and reduce maintenance costs

PS: In the era of explosive growth in computing power, our products are invisible guardians that ensure zero loss in the "golden channel" of data:

1. Metal connector: Avatar (electromagnetic shield) guards TB level data flow per second

2. Bellows: As a "dynamic armor", they resist millions of bends for fiber optic jumpers

3. Explosion proof armor: becoming the "bulletproof jacket" for edge data, facing extreme environmental impacts.

Future battlefield: Targeting the pain points of liquid cooled data center sealing (compatible with cold plates/immersion), developing 800G optical module specific nano coating connectors, and elevating our company from a "connector supplier" to a guardian of computing power foundation.

Learn More

Enquiry Now

Flexible cable glands for machinery movements.
Abrasion resistance for durability.

Oil and chemical resistance for maintenance.
Secure strain relief for operational safety.

Compliance with industry standards.
